Detailed Design
Detailed Engineering is the essential bridge between the basic engineering and construction phase of a project. During Detailed engineering all “Good for Construction“ and “Clash free drawings” are generated & reviewed along with the selected vendors / contractor.
There is continuous review of design/ engineering of various equipment and support function along with vendors and contractors. During this all the GA drawings and shop drawings of various disciplines are generated and accordingly composite drawings are generated and reviewed. There is close coordination & synergies among various discipline stake holders. This is highly interactive & progressive stage of the project.
This Stage involves coordination & consolidation of multiple disciplines to generate “Good for Construction” design & drawings, complete end to end.
Typically it includes the followings :
- Civil, Structural & Architectural Engineering
- Process Equipment / Machinery
- Interconnecting process piping
- Process / Plant Automation
- Process GMP drains
- Mechanical Engineering
- Pipe Racks & Piping
- Water System & Distribution
- Plumbing Engineering
- Electrical Engineering
- Field Instrumentations
- HVAC
- Clean Room Partitions (CRP)
- BMS / EMS
- Effluent Treatment System (ETP & STP)
- Plant drains
- Fire Fighting System
- Quality Laboratory
- Warehouse racking System
- Emergency System
- Surveillance System
- Other external services etc.
