Concept Design is the foundation & strategic documents for any project. Concept design package typically includes the overall frame work of the project. In Conceptual Design, Elomatic strives to capture all the possible information and all preliminary design which contributes in the successful overall design and implementation of the project. The key factor is the development of a fully GMP compliant design that considers processes, technologies & equipment, making them fit in the given space.
Concept Design is lead document to work out the complete design & engineering strategy of the project implementation till start – up of the facility. The major outcome of the Conceptual design is to develop the plant layout along with flow of resources, define the foot print of the facility, identify & size the major critical equipment and get an estimated investment budget.
The Conceptual Design is the base document for Basic Engineering and Detail Design of the project.
The Typical Conceptual Design Package Includes :
- Plant URS
- Project Quality Plan
- Process Flow diagrams (Block PFD)
- Layouts along with man – material flow
- Product and Waste Movement
- Classification layout
- Design basis report
- Concept design notes for Utilities
- Concept design notes for Electricals
- Concept design notes for HVAC
- Concept design notes for BMS & EMS
- Automation Philosophy
- Qualification / Validation Philosophy
- Time Schedule
- Budget Estimates etc.
